Speed:
3800 bph
Containers:
Glass
Formats:
0.375 L, 0.75 L, 1.5 L
Product:
Still wine

Depalletizer

Automatic depalletizer branded Oma model Depalblock 2000 built in 2002. It reaches speeds of 6000 BPH for the 0.75 lt format.
In addition to that, it processes formats such as 0.375 - 0.75 and 1.50 bottles.

This used depalletizer is supplied with all its accident prevention protections and also the user manuals.

The loading is carried out from above and there is neither a pad removal system nor a pallet warehouse.

However, there are spare parts available. Measurements: L: 2950 D: 2133 H: 2530 Weight: 1550 kg.
Consumption Volts: 380 Kw: 2 Hz: 50


Filling monoblock

The manufacturer of this monoblock is Ave Impianti and it is an Oceanic 16-16-4 model.
It works with the same formats from 0.375 - 0.750 – 1.500 at a speed of 3800 BPH. The rotation direction is clockwise and the status is currently in production. This machine is currently used for filling still wine.

Consisting of a rinser that has 16 clamps that does 2 treatments.

Then follows the 16-valve filling machine with fixed nozzle. Finally there is the 4-head cork capper which can process a diameter of up to 26 mm.

There are several spare parts for this machine.

Measurements: L: 4600 D: 2300 H: 3400
Volt consumption: 380 Hz: 50


Used capper

As regards the capper, it is branded Bertolaso ​​and the model is Alfa 110 Inox from 1995 with 1 head.

Clockwise rotation direction always complete with all available accident prevention and manual protections.

The operational status is currently in production and the type of container treated is 0.75 liter Bordeaux. The type of cap is Stelvin and the size is 30x60, while the type of neck is standard.

Measurements: L: 800 D: 900 H: 2600
Volt consumption: 380
capper

This machine is branded Robino and Galandrino model Fenix ​​2 from the year 2000. It is a used capper with 2 heads and the speed reached is 6000 BPH with the following formats: 0.375 – 0.750 – 1.500.

Accident prevention protections are present and manuals are also available with the necessary instructions.

The state is currently in production. The treated product is precisely still wine.

The types of capsules used are Enoterm polylaminate capsules. Weight: approx. 1800
Consumption Volts: 380 Kw: 4.5 Hz: 50


labeling machine

Extra Fix model 8T S3 E3 + S2 E2 Adhesive year 2005. Speed ​​of 3000 BPH on treated formats of 0.375 – 0.750 – 1.500 lt.

Machine currently in production in the line with its accident prevention protections and user manuals available.

Clockwise rotation direction with 3 water and glue stations + 2 adhesive stations.

Glue film adjustment is done manually and the centering system is photoelectric. Head adjustment is electric and also features output ironing. Measurements: L: 2800 D: 2250 H: 2050 Weight: 2000
Consumption Volts: 380 Kw: 5 Hz: 50


Carton forming

machine Case packing machine marked APE Module F systems from 2002 which forms 600 cartons per hour.

Currently in production always with protections and manuals available. The types of containers formed are 2 boxes of 6 or 1 box of 12 Bordeaux\magnum\mezzoBordeaux.

The machine has any spare parts.

Measurements: L: 1600 D: 1900 H: 1800 Weight: 500
Consumption Volts: 380 Kw: 1 Hz: 50


Case packer

Model Inca 1200 Used case packer branded APE Impi
