Detailed Technical Data Sheet: Used Hernault-Batignolles Parallel Lathe Model Jupiter 400x1500

Overview

The used Hernault-Batignolles Jupiter 400x1500 parallel lathe is a robust and versatile machine tool, designed to offer precision and reliability in metalworking. This model, used but well maintained, is ideal for mechanical workshops and for those who need a lathe with superior capacity and precision at a low cost. The used Hernault-Batignolles Jupiter 400x1500 cutter stands out for its solidity and the quality of workmanship it can guarantee.

Construction and Components

The Hernault-Batignolles Jupiter 400x1500 is built with high quality materials and includes several essential components for its operation:

• Brand and Model : Hernault-Batignolles, Jupiter 400x1500
• Working Dimensions : The length of the bench is 1500 mm, while the maximum working diameter is 400 mm.
• Type of Construction : Mechanically guided parallel lathe, designed to guarantee rigidity and stability during machining.
• Main Components:
  • Bench : Constructed of high quality cast iron to reduce vibration and improve accuracy.
  • Chuck : Large diameter for solid workpiece support.
  • Tailstock : To support long workpieces and improve stability.
  • Mobile trolley : For the longitudinal and transversal movement of the piece.

Mechanical Characteristics

The Hernault-Batignolles Jupiter 400x1500 lathe offers several mechanical features that make it an excellent choice for precision work:

• Spindle diameter : 400 mm
• Bench Length : 1500 mm
• Spindle Speed : Adjustable in different ranges to adapt to different types of processing.
• Movements:
  • Longitudinal Movement : To work along the length of the piece.
  • Transversal Movement : To work the external and internal part of the piece.

Usage Procedure

1. Preparation : Check that the lathe is installed on a stable and level surface. Make sure all components are clean and in working order.
2. Mounting the Workpiece : Place the workpiece in the chuck and secure it securely. Use the tailstock to support long workpieces.
3. Installing the Tool : Mount the turning tool in the tool slide, making sure it is well secured and aligned.
4. Speed ​​Setting : Adjust the spindle speed based on the type of material and the type of processing desired.
5. Starting the Lathe : Turn on the machine and start the turning process. Monitor processing and make necessary adjustments.
6. Inspection and Removal : At the end of the processing, turn off the lathe, remove the piece and check the quality of the work carried out.

Matching accessories

The Hernault-Batignolles Jupiter 400x1500 model can be equipped with various accessories to increase its capabilities:

• Turning Tools : Including threading, turning and milling tools.
• Clamping Devices : Clamps, chucks and locking devices for workpieces of various sizes.
• Additional tailstocks : To support longer pieces.
• Measuring Devices : Such as digital indicators for greater precision.

Mathematical Formulas for Optimal Use

To optimize the use of the Hernault-Batignolles Jupiter 400x1500 lathe , it is useful to know the following formulas:

1. Cutting Speed ​​(V_c):

   $$V$$

   Where:

   • NN $N$ is the spindle speed in rpm.
   • DD $D$ is the diameter of the piece in mm.

2. Advancement per Revolution (f):

   $$f$$

   Where:

   • FF $F$ is the feed rate in mm/min.
   • NN $N$ is the spindle speed in rpm.

Workable Materials

The Hernault-Batignolles Jupiter 400x1500 lathe is designed to process various materials:

• Metals : Steel, aluminium, brass and other ferrous and non-ferrous metals.
• Wood : For turning applications on pieces of wood.
• Plastics : Suitable for plastic and composite parts.

Maintenance

To keep your used Hernault-Batignolles Jupiter 400x1500 lathe in good condition:

• Lubrication : Perform regular lubrication of movements and components.
• Cleaning : Keep the workbench and surrounding areas clean of chips and dust.
• Periodic Checks : Check the condition of the tools and main components, and check that all adjustments and safety devices work correctly.

Evaluation of used cars

To evaluate the quality of a used Hernault-Batignolles Jupiter 400x1500 lathe :

• General Condition : Check for signs of wear or damage on components and workbench.
• Operation : Test the machine to ensure that all movements and adjustments are smooth and free from abnormal vibrations.
• Documentation : Make sure maintenance documentation is complete and all safety devices are certified.

Sectors of Use

The Hernault-Batignolles Jupiter 400x1500 lathe is versatile and finds application in:

• Metalworking Industry : For the processing of precision metal components.
• Wood sector : For turning and processing of wooden pieces.
• Fine Mechanics Industry : For the production of prototypes and high precision components.

Advantages of Buying a Used Car

Opting for a used Hernault-Batignolles Jupiter 400x1500 model lathe offers numerous advantages:

• Lower Cost : Allows you to acquire a quality machine at a more advantageous price than a new model.
• Immediate Availability : Reduces waiting times and allows you to start production immediately.
• Reliability : A well-maintained used one can guarantee excellent performance and long life.
