Used CNC Lathe CAMI TACN B60V – Excellent Deal for High Precision Productions

If you are looking for a used CNC lathe in excellent condition to improve your productivity and precision, the CAMI TACN B60V is the machine for you. This lathe is a real guarantee of quality and reliability, designed to offer high performance, millimeter precision and durability over time. Thanks to its power, versatility and compact size, the CAMI TACN B60V is perfect for complex processes in the industrial, mechanical and precision workshops.

Design and Components of the CAMI TACN B60V

Visually, the CAMI TACN B60V presents itself as a robust and compact machine, with a solid structure that guarantees stability even in the most demanding processes. Its dimensions are 2265 mm long , 1100 mm wide , and a height of 2250 mm , for a total weight of 2500 kg . The machine is equipped with a turret slide with a maximum stroke of 120 mm and a minimum distance between turret and gripper of 80 mm , which allows it to handle loads and tools of various sizes with precision.

The lathe is equipped with a 12 kW , which offers a speed range from 0 to 3000 rpm , allowing it to adapt to different machining needs with precise speed control. The transmission motor is coupled via a toothed belt , which guarantees efficiency and reduction of mechanical backlash.

Mechanical and Technical Characteristics of the CAMI TACN B60V

The CAMI TACN B60V is equipped with a series of technical specifications that make it ideal for the most complex and precise processes:

• Vector spindle motor power : 12 kW
• Spindle speed range : 0-3000 rpm
• Positioning resolution : 0.5 degrees
• Turret slide : Maximum stroke of 120 mm, with a rapid advance speed of 160 mm/min .
• Maximum longitudinal slide stroke : 90 mm
• Maximum transversal slide travel : 45 mm
• Rapid speed : 8000 mm/min
• Maximum force : 7000 N
• Turret diameter : 160 mm, with 6 holes (hole diameter: 31.75 mm or 1 ¼” ), which allow you to mount different tools with great ease.
• Tool change motor torque : 1 Nm, with a tool change speed of 0.3 sec , to minimize downtime.
• Maximum bar dimensions : Round – diameter 60 mm , Hexagon – side 52 mm , Square – side 42 mm .
• Tank capacity : 170 litres
• Hydraulic pressure : 70 bar
• Power supply : 400 V – 50 Hz
• Installed power : 16 kW

How to Use the CAMI TACN B60V

Using the CAMI TACN B60V is simple thanks to its intuitive interface and the CNC control system that allows you to program and manage every aspect of the processing with precision. Once the bar of material is inserted into the chuck, the CNC system takes care of managing the movements of the longitudinal and transversal slides, as well as quickly positioning and changing the tools. This high-speed tool changing system helps reduce machine downtime and increase production efficiency.

The operator can set processing parameters such as spindle speed, cutting depth and feed rate to achieve precise results according to the processed material.

Maintenance and Durability of the CAMI TACN B60V

The CAMI TACN B60V is a machine designed to last a long time with regular and adequate maintenance. Routine maintenance includes checking the lubricant level in the tank, checking the hydraulic pressure and cleaning the guides. It is also important to monitor the engine and timing belt to ensure that there are no signs of wear and that operations are always smooth and problem-free.

To prolong the useful life of the lathe and maintain high performance, it is essential to carry out periodic checks on the electrical and hydraulic components and replace the hydraulic oil filters when necessary.

Sectors of Use of the CAMI TACN B60V

The CAMI TACN B60V is widely used in the fields of precision mechanics , industrial component manufacturing , and prototyping . Thanks to its power and precision, it is suitable for working on metals, light alloys, reinforced plastics and composite materials. It is the ideal machine for those who need complex, high-speed machining, but also for those who want to optimize their production process economically without sacrificing quality.

Why Buy a Used CNC Lathe CAMI TACN B60V

Purchasing a used CAMI TACN B60V CNC lathe is an advantageous choice for those looking for a high quality machine at a competitive price. This model, being a certified used one, allows you to save considerably compared to purchasing a new machine, but with the certainty of obtaining a product with excellent performance and capable of satisfying the most complex needs.

When purchasing a used CAMI TACN B60V , it is essential to check that the machine has undergone a complete overhaul, that the hydraulic and electrical components are in good condition and that the CNC system works perfectly. Also make sure that there are no signs of wear on the mechanical components and that the machine has been properly maintained.

Conclusion

The CAMI TACN B60V CNC lathe represents an excellent opportunity for those looking for a high-performance, precise and long-lasting machine. With a motor power of 12 kW , a speed range from 0 to 3000 rpm , and a number of advanced features such as tool change speed of 0.3 sec and rapid tool change at 160 mm/min , it is ideal for more complex processes. If you are looking for a used CNC lathe that can offer precision and reliability, the CAMI TACN B60V is the right choice. Don't miss this opportunity!
