DIMENSIONS 2900x1200x1250
WEIGHT 2250kg
HEIGHT OF TIPS ON THE BENCH 215 mm.
DISTANCE BETWEEN POINTS 1500 mm.
MAX TURN ON THE BENCH 430 mm.
MAX TURNING ON THE CARRIAGE 270 mm.
MAX TURN ON THE BEZELS 160 mm.
SOCKET WIDTH 270 mm.
CHUCK NOSE CAMLOCK 8
CHUCK HOLE 78 mm.
SLEEVE DIAMETER 70 mm.
SLEEVE STROKE 200 mm.
Morse SLEEVE CONE 4
STROKE TRANSVERSAL SLIDE 250 mm.
TOOL SLIDE TRAVEL 140 mm.
SPINDLE SPEED N24
LONGITUDINAL TRANSVERSAL FEEDS N72
THREE-PHASE ASYNCHRONOUS MOTOR 10HP
nb complete instruction manual
